| 性能Performance | 1 | 额定载重量 rated loading | 800kg |
| 2 | 整机重量overall weight | 2400kg | |
| 3 | 斗容量 bucket capacity | 0.4m3 | |
| 4 | zui大牵引力maximum tractionforce | 50KN | |
| 5 | zui大掘起力 maximum breakout force | 60KN | |
| 6 | zui大爬坡能力maximum grade ability | 25℃ | |
| 7 | zui大卸载高度maximum dump height | 2500mm | |
| 8 | zui大卸载距离maximum dump reach | 800mm | |
| 9 | 整机外形尺寸overall dimension (L×W×H) | 4380*1300*2450mm | |
| 发动机Engine | 10 | 型号model | 潍坊490 |
| 11 | 型式type | 直列\水冷\干缸套\直喷lnline water cooling dry cylinder injection | |
| 13 | 额定功率rated power | 37kw-2400r/min | |
| 14 | zui大扭矩maximum torque | 147N.M | |
| 15 | 排放标准 Emission standards | 国二 | |
| 传动系统 Transmission system | 16 | 变矩器型式torque converter | 单级四元件双涡轮液力变矩器 |
| 17 | 变速箱型式gearbox mode | 行星式动力变速箱 | |
| 18 | 档位数gears | 前进档两个，倒退档一个 2 forward shift 1reverse shift | |
| 19 | zui高车速maximum speed | 25km/h | |
| 驱动桥Drive axles | 20 | 主减速式：main reducing spiral | 螺旋伞齿轮一级减速bevel gear grade 1reduction |
| 21 | 轮边减速型式decelerating mode | 一级行星减速 Planetary reduction grade 1 | |
| 22 | 轴距wheel base (mm) | 1985mm | |
| 23 | 轮距wheel tread | 1100mm | |
| 液压 系统 Hydraulic system | 24 | 系统工作压力system working pressure | 16MPa |
| 25 | 动臂提升时间boom lifting time | 8.9s | |
| 26 | 三项和total time | 10±0.2s | |
| 制动系统 Brake system | 27 | 行车制动service brake | 油顶油鼓式四轮制动 Four-wheel brake with oil drum on oil cap |
| 28 | 驻车制动parking brake | 手动鼓式Hand Drum | |
| 轮胎 Tyre | 29 | 规格type specification | 825—16 |
| 30 | 前轮气压front tyre pressure | 0.4Mpa | |
| 31 | 后轮气压rear tyre pressure | 0.35Mpa |
|
