| Performance | 1 | 额定载重量rated loading | 3000kg |
| 2 | 整机重量overall weight | 9900kg | |
| 3 | 斗容量bucket capacity | 1.8m3 | |
| 4 | zui大牵引力maximum tractionforce | 95KN | |
| 5 | zui大掘起力 maximumbreakout force | 127KN | |
| 6 | zui大爬坡能力maximum grade ability | 30℃ | |
| 7 | zui大卸载高度maximum dump height | 3200mm | |
| 8 | zui大卸载距离maximum dump reach | 1006mm | |
| 9 | 整机外形尺寸overall dimension (L×W×H) | 6890*2430*3070mm | |
| 10 | zui小转弯半径minimum turning radius | 5097mm | |
| 发动机Engine | 11 | 型号model | Deutz enginesWP6G125E22 |
| 12 | 型式type | 直列、水冷、四冲程、直喷 Vertical, in-line, water cooled, 4-stroke diesel engine | |
| 13 | 汽缸数-缸径*行程NO. of cylinder-bore*stroke | 6-108*125 | |
| 14 | 额定功率rated power | 92kw—2200r/min | |
| 15 | zui大扭矩maximum torque | 500N.m | |
| 16 | zui低燃油消耗率 min. fuel-consume ratio | ≦210Kw/h | |
| 传动系统 Transmission system | 17 | 变矩器型式torque converter | YJ315-X |
| 18 | 变速箱型式gearbox mode | 定轴常啮合式428型 Power shaft normally engaged straight gear | |
| 19 | 档位数gears | 前进档4个，倒退档2个 4forward 2 reverse | |
| 20 | zui高车速maximum speed | 40km/h | |
| 驱动桥Drive axles | 21 | 主减速式：main reducing spiral | 螺旋伞齿轮一级减速bevel gear grade 1reduction |
| 22 | 轮边减速型式decelerating mode | 一级行星减速 Planetary reduction grade 1 | |
| 23 | 轴距wheel base (mm) | 2660mm | |
| 24 | 轮距wheel tread | 1800mm | |
| 25 | zui小离地间隙ground clearance | 400mm | |
| 液压系统 Hydraulic system | 26 | 系统工作压力system working pressure | 16,5MPa |
| 27 | 动臂提升时间boom lifting time | 4.83S | |
| 28 | 三项和total time | 9.15±0.5s | |
| 制动系统 Brake system | 31 | 行车制动service brake | 气顶油钳盘式四轮制动 air assist disc brake on 4 wheels |
| 32 | 驻车制动parking brake | 手动嵌盘式 Manual disk brake | |
| 轮胎 Tyre | 33 | 规格type specification | 17.5-25 |
| 34 | 前轮气压front tyre pressure | 0.4Mpa | |
| 35 | 后轮气压rear tyre pressure | 0.35Mpa |
|
